CMF-W300-1xXXC-CF438
SPECIFICATIONS
- Current rating: 5A AC, DC
- Voltage rating: 250V AC, DC
- Temperature range: -25°C~+105°C
- Contact resistance: 10m OHM Max
- Insulation resistance: 1000M OHM Min
- Withstanding voltage: 1500V AC/minute
- Finished: Brass/Tin-plated
- Housing Material: LCP, UL94V-0
- Color: Black
